CATIA V5 Workbook Release V5-6 R2013

About this book

This workbook is an introduction to the main Workbench functions CATIA V5 has to offer. The books objective is to instruct anyone who wants to learn CATIA V5 through organized graphically rich step-by-step instructions on the softwares basic processes and tools. This book is not intended to be a reference guide. The lessons in this workbook present basic real life design problems along with the workbenches toolbars and tools required to solve these problems. Each lesson is presented with step-by-step instructions. Although most of the steps are detailed for the beginner the steps and processes are numbered and bolded so the more experienced user can go directly to the subject area of interest. Each lesson consists of an introduction objectives an introduction to the workbench and toolbars used in the lesson step-by-step instructions and concludes with a summary. Review questions and additional practice exercises are at the end of each lesson. The workbenches covered in this workbook are Sketcher Part Design Drafting Assembly Design Generative Shape Design DMU Navigator and Rendering/Real Time Rendering Knowledgeware Kinematics and Generative Structural Analysis.
