OrCAD PSpice for Windows Volume 1: DC and AC Circuits (3rd Edition)

OrCAD PSpice for Windows Volume 1: DC and AC Circuits (3rd Edition) by Goody, Roy W.. paperback edition. ISBN: 9780130157966.

A circuit simulation book that addresses PSpice for Windows! Using a careful step-by-step process, this book takes readers from a simple dc circuit with its customary current and voltage measurements, through a damped resonant circuit requiring rise time to characteristics, to a complex analog/digital circuit that demands sophisticated timing and frequency measurements. Multi-level activities, examples, and exercises allow users to draw circuits directly on the screen, exactly as they would to create initial designs. It also enables them to analyze the circuits using PSpice,—and shows the circuit displayed at a level of detail unavailable through conventional techniques. This book also includes instruction in advanced techniques such as Monte Carlo and Performance. For instruction in DC/AC and devices, operational amplifiers, digital, analog, and filter design. n.
