Technical Graphics Communication (Irwin Graphics Series)

Technical Graphics Communication (Irwin Graphics Series) by Editor-Gary R. Bertoline; Editor-Leonard O. Nasman. hardcover edition. ISBN: 9780256229813.

The Graphics Drawing Workbook is meant to be used with either Technical Graphics Communications 2nd Edition or Fundamentals of Graphics Communications 2nd Edition. However the workbook can be used with any good reference text including Graphics communication for engineers by this author. There are workbook problems for every major topic normally taught in an engineering or technical drawing course. Most of the problems can be drawn with instruments or sketched. a special emphasis has been put on freehand sketching in this workbook in response to the increased use of CAD in many technical drawing courses. It is expected that the instructor will supplement these problems with others from the text to fully reinforce technical drawing topics.
