The Professional Practice of Architectural Working Drawings

About this book

The practical comprehensive handbook for creating effective architectural drawings In one beautifully illustrated volume The Professional Practice of Architectural Working Drawings Fourth Edition presents the complete range of skills concepts principles and applications that are needed to create a full set of architectural working drawings. Chapters proceed logically through each stage of development beginning with site and floor plans and progressing to building sections elevations and additional drawings. Inside youll find: Coverage of the latest BIM technologies Environmental and human design considerations Supplemental step-by-step instructions for complex chapters Five case studies including two that are new to this edition Hundreds of computer-generated drawings and photographs including BIM models three-dimensional models and full-size buildings shown in virtual space Checklists similar to those used in architectural offices Tips and strategies for complete development of construction documents from schematic design to construction administration With an emphasis on sustainability throughout this new edition of The Professional Practice of Architectural Working Drawings is an invaluable book for students in architecture construction engineering interior design and environmental design programs as well as professionals in these fields.
