A Manual of Construction Documentation

From information on standard utility graphics through specifics on schedules and sequencing this book covers every aspect of the working drawings and schedules that comprise a standard set of construction documents: Site Plans Floor Plans Roof Plans Reflected Ceiling Plans Exterior Elevations Building Sections Wall Sections Vertical Transportation Systems Enlarged Plans and Interior Elements Schedules Details Step-by-step graphics illustrate the precise sequencing of each drawing presenting a system that can be used with some modification on virtually any type or size of commercial building. An invaluable teaching tool and reference.
